Bossweld TIG 320X Welder 415V X-Series AC/DC – Water & Air-Cooled Options

Bossweld TIG 320X Welder 415V X-Series AC/DC – Water & Air-Cooled Options

by BossWeld
$3,572.45
Choose Your Cooling Method:

Notify me when back in stock

3 Phase

16mm

Aluminium, Mild Steel,
Stainless Steel, Brass,
Cast Iron

3.2mm Tungsten

15kVA

Bossweld X-Series AC/DC TIG 320X Welder – Unmatched Performance for Professionals

The Bossweld X-Series AC/DC TIG 320X Welder is the ultimate tool for professional tradespeople and maintenance technicians. Designed for precision, power, and versatility, this advanced TIG and stick welder is engineered to handle complex welding projects across a range of materials, including aluminium, mild steel, stainless steel, brass, and cast iron. With air-cooled and water-cooled options available, this welder is tailored to meet the diverse needs of demanding professionals.

Product Highlights

Advanced Technology for Superior Welding

  • IGBT Inverter Technology: High efficiency, reliability, and smooth arc performance.

  • Fully Adjustable Weld Cycle: Achieve unmatched precision for even the most complex projects.

Unparalleled Output Power

  • Maximum output of 320 Amps delivers exceptional performance.

  • Wide operating range from 10 to 320 Amps, suitable for various applications.

Enhanced Control & Flexibility

  • Adjustable Pulse Control: Creates refined weld beads with aesthetic and structural perfection.

  • Pre- and Post-Gas Flow Adjustment: Ensures precision and reduces contamination.

  • AC Balance Adjustment: Maximises cleaning action and penetration for aluminum welding.

  • Selectable Waveforms: Choose from AC Square, AC Sine, AC Triangle, and DC modes for ultimate versatility.

Ease of Use

  • High-Frequency Arc Start: Enables precise and reliable arc initiation.

  • Lift Arc TIG Option: Perfect for environments sensitive to high-frequency arcs.

  • Digital LED Display: Enhances accuracy and simplifies operation.

  • Trigger Modes: Includes 2T and 4T latching options for operator convenience.

Cooling System Options

  • Air-Cooled Package: Equipped with the durable Agility 26F Current Control TIG Torch.

  • Water-Cooled Package: Features a high-performance cooling system for extended duty cycles.

Package Comparison

Feature/Item Air-Cooled Package (SKU: 692345) Water-Cooled Package (SKU: 692346)
Welder Bossweld TIG 320X Inverter Welder 415V Bossweld TIG 320X Inverter Welder 415V
Torch 4-meter Agility 26F Current Control TIG Torch 4-meter water-cooled TIG torch
Electrode Holder 3-meter (600 Amp) 3-meter
Earth Clamp 3-meter 3-meter
Gas Hose 3-meter (5mm ID) 3-meter (5mm ID)
Regulator Argon regulator bobbin (dual stage) Argon regulator bobbin
Additional Components - Bossweld Water Cooler 415V (compatible with X-Series)
Bossweld Trolley (suits MST 350/500X & AC/DC 320X)
Operators Manual Included Included
Primary Plug Not fitted; requires installation by a licensed electrician Not fitted; requires installation by a licensed electrician

Optional Accessories

  • Foot Controller: 3m Bossweld Foot Controller (P/N: 660201).

  • Air-Cooled Torch Options:

    • 4m Agility 26F (P/N: 95.26F.4.1.CC12A).

    • 8m Agility 26F (P/N: 95.26F.8.1.CC12A).

  • Water-Cooled Torch Options:

    • 4m Agility 18F (P/N: 95.18F.4.1.CC12A).

    • 8m Agility 18F (P/N: 95.18F.8.1.CC12A).

  • Trolley: Bossweld Trolley (P/N: 699570).

  • Arc Lead Sets (4m):

    • P/N: 504435 (600 Amp).

    • P/N: 504450 (400 Amp).

  • Plugs:

    • 10A 3-phase (P/N: 600608).

    • 20A 3-phase (P/N: 600609).

    • 32A 3-phase (P/N: 600610).

  • Water Cooler Liquid: 5L Coolant (P/N: 600906).

Troubleshooting & Operational Guidance

Error Codes

  • E01: Thermal overload protection triggered; allow cooling before resuming.

  • E02: Input power error; verify voltage and phase alignment.

  • E03: Gas flow interruption; check connections and flow regulator.

Common Faults

  • No Arc Start: Ensure proper tungsten grinding and verify HF settings.

  • Erratic Arc: Check ground clamp connections and tungsten contamination.

Safety Notes

  • Maintain at least 30cm clearance for ventilation.

  • Recommended gas flow rate: 10–15 L/min.

  • Use a dedicated tungsten grinding wheel to prevent contamination.

Why Choose the Bossweld TIG 320X AC/DC Welder?

  1. Precision and Performance: Ideal for professionals demanding accuracy and power.

  2. Versatile Welding Options: Supports AC/DC TIG and DC Stick welding, as well as gas/gasless operations.

  3. Robust Durability: With a protection class of IP23 and advanced cooling options, the welder is built to last.

  4. Comprehensive Warranty: Backed by a 3-year limited warranty for peace of mind.

  5. Tailored Solutions: Available in air-cooled and water-cooled configurations to suit specific project needs.

Enhance your welding capabilities with the Bossweld X-Series AC/DC TIG 320X Welder. Designed for professionals, this powerhouse combines advanced technology, robust performance, and exceptional versatility to meet the demands of modern welding applications. Choose between air-cooled and water-cooled options to achieve unparalleled results on every project.
